| Frame | Galvanized iron , Aluminum , Stainless steel |
|---|---|
| Filter material | HEPA filter |
1. With high performance, ultra-slim design, and proven performance,air velocity of the filter is made more even.
2. The cabinet is made of cold-rolled steel plate sprayed or made of stainless steel, compact structure and beautiful appearance;
3. Using direct-drive high efficiency centrifugal fan(with a noise level of 56db), with low noise, small vibration and long life, maintenance-free.
4. Various controllers can be applied (On/Off, 3 Step etc.)
| All sizes and styles can be customized | |||||||
| Model | FFU-1 | FFU-2 | FFU-3 | FFU-4 | |||
| Size (WxLxHmm) | 575*575*240 | 575x875x240 | 575x1175x240 | 875x1175x240 | |||
| Air chamber material | Galvalume / aluminum / stainless steel | ||||||
| Air Flow (m³/h) | 400~700 | 800~900 | 1000~1100 | 1600~1700 | |||
| Air velocity (m/s) | 0.35~0.55 | 0.35~0.55 | 0.35~0.55 | 0.35~0.55 | |||
| Total pressure (Pa) | 165 | 175 | 185 | 255 | |||
| Power (W) | 75 | 85 | 95 | 235 | |||
| Weight (kg) | 17 | 27 | 37 | 42 | |||
| Noise dB (1m below the HEPA filter) |
55~63 | ||||||
| Vibration (mm/s) | 0.2~0.7 | ||||||
| Power supply | 220V 1PH 50/60Hz (330V 3PH 50/60Hz 110V 1PH 50/60Hz) | ||||||
| Control mode | 3 levels adjustable manually or group control by computer | ||||||
| Options | DOP inject port / DOP sample port / differential pressure drop test port /
differential pressure drop alarm device |
||||||
| HEPA filter | Size (WxHxDmm) | 570x570x69 | 570x870x69 | 570x1170x69 | 870x1170x69 | ||
| Efficiency | 99.99% 0.3μm | ||||||
| Frame | High quality anodized aluminum | ||||||
| Initial
pressure drop |
110Pa@0.45m/s±15% | ||||||
| Trait | PU foam endless gasket | ||||||
Semiconductor, electron, flat-panel display, disc-drive, manufacture and optics, bio-engineering, clean bench, clean room , or any other places.
